Dell PowerProtect Data Manager Deploy D-PDM-DY-23

Data Manager Deploy

Formally validate your skills to deploy, configure, troubleshoot, integrate, and upgrade Dell PowerProtect Data Manager — protecting MS-SQL, Oracle, VMware, SAP HANA, MS Exchange, Kubernetes, File Systems, and NAS in diverse enterprise environments.

PPDM Appliance VMware Protection MS-SQL Oracle SAP HANA Kubernetes NAS / File System SLA Compliance Protection Policies Disaster Recovery Search Engine MS Exchange PPDM Reports DD Integration

What You Will Learn

Three PowerProtect Data Manager Modules

Master Dell PowerProtect Data Manager — from initial deployment and upgrade through multi-workload integration (VMware, SQL, Oracle, K8s, SAP HANA) to full policy administration, SLA compliance, and disaster recovery.

Module 01

PowerProtect Data Manager Deployment and Initial Configuration

›PPDM components — PPDM vApp (OVA deployed on vSphere), Cloud Edition (deployed in AWS/Azure/GCP), protection agents (application agent installed on protected hosts), DD storage (target for backup data)
›Deployment requirements — vSphere prerequisites (vCenter version, datastore sizing: 1 TB+ for PPDM appliance), network requirements (DNS, NTP, management VLAN), DD system (DD OS 7.x+, DD Boost licence)
›PPDM deployment — deploying OVA from vSphere Client (resource pool, datastore, networking), completing first-run wizard (admin password, licence, network settings, DD storage registration)
›Initial configuration — adding protected systems (vCenter, application hosts), configuring protection storage (DD systems, DD Boost MTrees), setting system-wide timezone and email notification preferences
›Upgrade procedure — downloading PPDM upgrade package, uploading via UI (Administration → Software Updates), running pre-upgrade health check, executing upgrade (rolling restart), and verifying post-upgrade version and agent compatibility

Module 02

PowerProtect Data Manager Integration

›MS-SQL — requirements (PPDM agent on SQL host, sysadmin role for PPDM service account), configuring SQL asset source, creating protection policy (FCI/AAG awareness, log backup frequency), performing application-consistent backup and granular table-level restore
›Oracle — requirements (PPDM Oracle agent, ORACLE_HOME environment variable), asset discovery (CDB/PDB detection), policy configuration (RMAN channel count, archive log settings), backup and PIT recovery workflow
›VMware vSphere — agentless VM protection via vCenter API (VADP), configuring vCenter as asset source, VM policy (consistency level: crash vs app-consistent, exclusion of swap disks), instant access recovery (mount VM directly from DD), and VMDK-level file-level recovery
›SAP HANA — agent installation on HANA host, HANA plug-in configuration (HANA system ID, tenant DB credentials), full and incremental log-based backup, point-in-time restore workflow
›MS Exchange — agent on Exchange server, DAG discovery, Exchange policy (database selection, VSS-based backup), item-level recovery using PPDM search engine
›Kubernetes — PPDM Kubernetes plug-in (velero-based), namespace protection policies, PVC snapshot and backup to DD, cross-namespace and cross-cluster restore workflow
›File System and NAS — file system agent (Windows/Linux), configuring NAS asset sources (NFS/CIFS mount points), policy (full/incremental schedule, retention), and performing granular file-level recovery

Module 03

PowerProtect Data Manager Administration

›Protection Policies — creating policy (workload type, asset selection, schedule: full/incremental, retention tiers, DD target), policy compliance dashboard (green/amber/red SLA status per asset)
›SLA Compliance — defining SLA objectives (RPO, retention), monitoring compliance violations, drilling into non-compliant assets, and configuring alert notifications (email, SNMP) for SLA breaches
›Search Engine — deploying PPDM Search nodes, indexing file-system and SQL backups for granular search, performing keyword/metadata search across backup copies, and restoring individual files from search results
›Protection Rules — auto-assigning assets to policies using dynamic rules (vCenter tags, hostname regex, app type), reducing manual policy assignment effort at scale
›Reports — built-in reports (asset protection status, capacity trends, SLA compliance, job history), scheduling automated email delivery of reports, and exporting CSV for executive dashboards
›Disaster Recovery — configuring PPDM DR (PPDM metadata backup to DD, DR bundle download), recovering PPDM appliance from DR bundle, and testing DR runbook periodically
›Monitoring and Troubleshooting — dashboard overview (jobs in progress/failed, capacity, compliance), job log drill-down, downloading PPDM support bundle (Administration → Support), checking PPDM agent connectivity, resolving common errors (credential expiry, DD connectivity, vCenter certificate issues)

Full Curriculum

3-Module D-PDM-DY-23 Programme

Complete PPDM deployment curriculum — from appliance installation and initial configuration through multi-workload integration and full administration including SLA, DR, search, and troubleshooting.

›Identify PPDM components — PPDM appliance (vApp OVA or Cloud Edition), protection agents (per workload), DD storage target, and vProxy (agentless VMware proxy)
›List deployment requirements — vSphere 6.7/7.0+, 8 vCPU / 32 GB RAM / 1 TB+ datastore for appliance, DNS/NTP/management network, DD OS 7.x+ with DD Boost licence
›Deploy PPDM from OVA — importing OVF template in vSphere Client, selecting resource pool and datastore, configuring initial network properties, completing setup wizard (admin password, SMTP, licence key)
›Register DD storage — adding DD system (IP, DD Boost credentials), verifying DD Boost connectivity, and viewing registered storage capacity in PPDM dashboard
›Upgrade PPDM — uploading upgrade package via Administration → Software Updates, running pre-upgrade compatibility check, executing upgrade, monitoring rolling restart, verifying version and agent upgrade prompts

›MS-SQL — installing PPDM agent on SQL Server host, configuring sysadmin service account, creating SQL asset source in PPDM, building protection policy (AAG/FCI awareness, transaction log backup every 15–60 min), performing SQL restore (full DB, point-in-time, item-level table restore)
›Oracle — agent install on Oracle host, configuring ORACLE_HOME and TNS, PPDM Oracle asset discovery (CDB + PDB), policy (RMAN channels, archive log retention), full backup and point-in-time clone recovery
›VMware — configuring vCenter as asset source, agentless VM protection via VADP vProxy, policy (app-consistent via VMware Tools quiesce, swap/temp disk exclusions), instant access (mount VM from DD backup), VMDK restore, and file-level recovery
›SAP HANA — installing PPDM HANA plugin, registering HANA system (SID, tenant DB, HANA OS credentials), creating protection policy (full + incremental + log backup), point-in-time restore and recovery using HANA Studio
›MS Exchange — PPDM agent on Exchange, DAG discovery, VSS-based mailbox database backup, item-level restore using PPDM search results (individual emails, contacts, calendar items)
›Kubernetes — deploying PPDM k8s plugin (Velero integration), namespace-level protection policy, PVC snapshot backup to DD, cross-namespace restore and cross-cluster recovery workflow
›File System and NAS — Windows/Linux file system agent install, NFS/CIFS NAS asset registration, policy (full + incremental, retention tiers), granular file/folder restore from PPDM interface

›Configure Protection Policies — selecting workload type and assets, defining schedule (full/incremental/log), setting retention (primary copy + remote replication copy), selecting DD target storage
›Configure SLA Compliance — defining RPO objectives per policy, monitoring SLA dashboard (green/amber/red), drilling into non-compliant assets to identify missed backups, alerting via email/SNMP
›Configure Search Engine — deploying search nodes, enabling indexing in file system and SQL policies, performing keyword/path/metadata search across backup inventory, restoring files directly from search results
›Configure Protection Rules — creating dynamic rules using asset attributes (vCenter tags, hostname wildcards, OS type) to auto-assign new assets to correct policies without manual intervention
›Configure Reports — viewing built-in reports (asset status, job history, capacity trends, compliance), scheduling automated email delivery (PDF/CSV), and interpreting capacity forecast for capacity planning
›Configure Disaster Recovery — generating DR bundle (metadata backup to DD), downloading and storing DR bundle offsite, restoring PPDM appliance from DR bundle (deploy new OVA, import DR bundle), validating recovered PPDM
›Troubleshoot — PPDM dashboard job failure analysis (error code lookup), reviewing agent log files, collecting support bundle via UI, resolving common issues: agent version mismatch, DD connectivity errors, vCenter certificate trust, credential expiry alerts

Live Training

Live Instructor

Mon–Fri · Weekend batches

Recording

Live class recording included

30 Days

1.5 hrs/day weekday · 3 hrs weekend

Course Materials

Study notes and resources

Tech Support

Call / WhatsApp support

Working Hours

Mon–Fri · 9 AM – 6 PM

Enroll Now Download Brochure

Have Questions?

Chat with our Dell-certified PPDM trainers instantly.

WhatsApp Us

Ready to Deploy Dell PowerProtect Data Manager?

Earn the D-PDM-DY-23 Dell Proven Professional certification and validate your expertise in deploying and managing PPDM across VMware, SQL, Oracle, SAP HANA, Kubernetes, and NAS environments with SLA-driven protection policies.
