Dell Unity Deploy D-UN-DY-23 - Zetlan Technologies

Deploy

For engineers deploying Dell Unity storage systems — covering Unity XT hardware and Unity VSA, installation and service tasks, system administration, block/file/VMware storage provisioning, FAST Cache, data reduction, and snapshots and replication for data protection.

Unity XT Install UnityVSA Deploy Block Provisioning NFS/SMB File VMware Datastores FAST Cache Data Reduction FAST VP Snapshots Async Replication Host Access Unisphere for Unity

What You Will Learn

Six Unity Deploy Modules

Master Unity XT and UnityVSA platform concepts, installation and service, system administration, block/file/VMware storage provisioning, data efficiency technologies, and data protection with snapshots and replication.

Module 01

Unity Platform Concepts

›Unity product family — Unity XT hybrid/all-flash arrays: 300/300F, 380/380F, 480/480F, 680F, 880F; Unity VSA virtual storage appliance; use case differentiation
›Unity hardware architecture — dual Storage Processors (SP A and SP B) active-active; back-end SAS/NVMe drive enclosures; DAE (Disk Array Enclosure) expansion; front-end FC/iSCSI/NAS ports
›UnityVSA — deploy as OVF on VMware vSphere; vCenter Server requirements; three license editions (Developer, 4 TB Community, Subscription); VSA resource requirements
›Unisphere for Unity — browser-based HTML5 management GUI; REST API; Unity CLI (uemcli); storage processor isolation and management interfaces
›Connectivity — FC SAN (8/16/32 Gb), iSCSI (1/10/25 GbE), NAS (10/25 GbE); direct-attached and SAN fabric connectivity; multi-initiator multi-path I/O
›Storage pool types — dynamic pools (flexible RAID, 5+1 RAID, mixed tier); traditional pools (RAID-5, RAID-6, RAID-10) with user-defined drives

Module 02

Installation and Service

›Unity XT installation — rack mounting Unity XT chassis; SPS (Standby Power Supply) cabling; backend SAS cabling to DAE expansions; front-end SFP/FC cabling
›Unity XT initial configuration — connect to initial Unisphere wizard via SP management port; set hostnames, DNS, NTP; update software version; license activation
›UnityVSA deployment — download OVF from Dell Support; deploy to vSphere; configure network adapters: management, iSCSI, NFS; launch VSA Unisphere for initial setup
›Service tasks — replace failed drives (SSD/HDD hot-plug); SP replacement procedure; DAE component replacement; firmware update for drives and SP
›Unity service utilities — Unisphere service menu; uemcli commands for hardware status; collect system logs for Dell EMC support; run diagnostics from Unisphere

Module 03

System Administration

›Unisphere for Unity navigation — dashboard: system health, capacity, performance; storage section tree; settings menu; alert and event log management
›User management — local user accounts; Active Directory/LDAP integration; role-based access control (Administrator, StorageAdmin, Operator, VM Administrator)
›Support settings — ESRS (Embedded Service Enabler) registration for proactive support; call home alert configuration; DNS and NTP verification; SSL certificate management
›System settings — SP hostnames; iSCSI network configuration (portals); network interfaces for NAS; jumbo frame MTU settings; VLAN tagging
›Monitoring and alerting — configure email and SNMP alert recipients; set performance threshold alerts; schedule health checks; interpret hardware status indicators

Module 04

Storage Provisioning and Access

›Dynamic and traditional pools — create dynamic pool with Flash and SAS drives; assign RAID type per tier in traditional pool; pool capacity monitoring; pool expansion
›Block storage — create LUNs (thick and thin provisioned); set storage pool, size, SP owner; host access: add initiators to Unity; create host, host group; LUN Masking View
›File storage — create NAS Server with SP affinity; configure file interfaces (NFS, SMB); create file system; export NFS share with access controls; create SMB share with AD integration
›VMware storage — create VMFS datastore for ESXi; NFS datastore for ESXi; Unity vSphere Plugin for Unisphere integration; vVols Protocol Endpoint and Storage Container creation
›Host access — register FC initiators; configure iSCSI portals and CHAP authentication; SMB/NFS file access for Linux/Windows; multi-path I/O (PowerPath, MPIO) host setup

Module 05

Storage Efficiency

›FAST Cache — configure all-flash SSD FAST Cache pool; enable FAST Cache for LUNs and file systems; FAST Cache read/write caching behavior; monitor cache hit rates in Unisphere
›File Level Retention (FLR) — enable FLR on file system; minimum, maximum, and default retention periods; auto-lock mode vs. compliance mode; FLR event log access
›Data Reduction — enable inline deduplication and compression for dynamic pools; view data reduction ratio and space savings; understand data reduction impact on write performance
›FAST VP — automated storage tiering for traditional pools; promotion/demotion schedules; monitoring tier distribution; initial tier allocation policy; manual relocation
›Thin provisioning and space reclamation — thin LUN subscription ratios; monitor over-subscription; space reclamation with Unisphere; zero-page reclamation for VMware vSphere

Module 06

Data Protection and Mobility

›Snapshots — create snapshots for LUNs, file systems, and VMware datastores; consistency groups for multi-volume consistent snapshots; attach snapshot for host access; restore from snapshot
›Snapshot schedules — create daily/weekly/monthly snapshot schedules; retention policy for automatic deletion; monitor snapshot counts and capacity usage
›Synchronous replication — Unity Metro sync replication; configure replication session between two Unity systems; RPO = 0; failover and failback procedures for sync replication
›Asynchronous replication — configure async replication session; RPO target (minimum 5 minutes); bandwidth throttling; pause/resume replication; modify replication interval
›Replication management — monitor replication session health in Unisphere; alert on replication lag; scheduled/unscheduled sync; reverse replication after site recovery

Full Curriculum

6-Module D-UN-DY-23 Programme

Complete Unity deployment curriculum — platform concepts, installation, system admin, storage provisioning, data efficiency, and data protection covering all exam domains.

›Unity XT hardware models: hybrid/all-flash arrays; Unity VSA virtual appliance
›Dual SP active-active architecture; DAE expansion; front-end ports
›Pool types: dynamic (flexible RAID) vs traditional; unisphere GUI overview
›UnityVSA OVA deployment; license editions; resource requirements

›Unity XT rack installation; SPS cabling; back-end SAS; front-end FC cabling
›Initial Unisphere wizard: DNS, NTP, hostname, licensing
›UnityVSA OVF deploy on vSphere; network adapter configuration
›Service tasks: hot-plug drives, SP replacement, firmware update, log collection

›Unisphere navigation: dashboard, storage tree, settings, alerts
›User management: local accounts, AD/LDAP, role-based access control
›Support settings: ESRS, call home, DNS, NTP, SSL certificates
›Monitoring: email/SNMP alerts, performance thresholds, health checks

›Dynamic and traditional pool creation, expansion, monitoring
›Block: LUN create (thick/thin), host access, initiator registration, masking
›File: NAS Server, NFS/SMB shares, AD integration, access control
›VMware: VMFS/NFS datastores, vSphere Plugin, vVols PE/SC setup

›FAST Cache: SSD cache pool, enable per-LUN, monitor hit rates
›Data Reduction: inline dedup and compression for dynamic pools
›FAST VP: automated tiering, tier distribution, relocation schedules
›FLR: file retention compliance, auto-lock mode, retention periods

›Snapshots: block/file/VMware; CG consistency groups; attach; restore
›Snapshot schedules and retention policies
›Async replication: sessions, RPO target, pause/resume, failover
›Sync replication: metro mode RPO=0; failover and failback procedures

Live Training

Live Instructor

Mon–Fri · Weekend batches

Recording

Live class recording included

30 Days

1.5 hrs/day weekday · 3 hrs weekend

Course Materials

Study notes and resources

Tech Support

Call / WhatsApp support

Working Hours

Mon–Fri · 9 AM – 6 PM

Enroll Now Download Brochure

Have Questions?

Chat with our Dell-certified Unity trainers instantly.

WhatsApp Us

Ready to Deploy Dell Unity Storage?

Earn the D-UN-DY-23 Dell Proven Professional certification and prove your skills deploying Unity XT and UnityVSA systems — from initial installation through block, file, VMware provisioning, FAST Cache, data reduction, and replication.
